Arid Land Geography ›› 2025, Vol. 48 ›› Issue (11): 1893-1902.doi: 10.12118/j.issn.1000-6060.2024.701
• Climate Change • Previous Articles Next Articles
WANG Chunyong(
), LI Chaofan(
), HAN Qifei
Received:2024-11-13
Revised:2024-12-30
Online:2025-11-25
Published:2025-11-26
Contact:
LI Chaofan
E-mail:Wangchunyong0108@163.com;lcf8709@163.com
WANG Chunyong, LI Chaofan, HAN Qifei. Spatiotemporal dynamics of potential evapotranspiration and its response to land use change on the northern slope of Tianshan Mountains from 2000 to 2021[J].Arid Land Geography, 2025, 48(11): 1893-1902.
Tab. 3
Transition matrix of land use type change area on the northern slope of Tianshan Mountains from 2000 to 2021 /hm2"
| 土地利用类型 | 耕地 | 林地 | 草地 | 水体 | 未利用地 | 城市建设用地 | 总计 |
|---|---|---|---|---|---|---|---|
| 耕地 | 1370711.97 | 1804.41 | 163960.11 | 6441.21 | 5284.44 | 25919.01 | 1574121.15 |
| 林地 | 381.42 | 334094.58 | 114.93 | 15.57 | 0.36 | 11.70 | 334618.56 |
| 草地 | 620893.44 | 71612.10 | 5092289.28 | 15521.40 | 491057.91 | 47727.63 | 6339101.76 |
| 水体 | 4989.69 | 1665.90 | 9420.57 | 349142.40 | 57799.71 | 2760.39 | 425778.66 |
| 未利用地 | 242271.09 | 519.93 | 387853.11 | 82041.57 | 5465918.70 | 34508.52 | 6213112.92 |
| 城市建设用地 | 34.02 | 0.00 | 29.97 | 140.04 | 7.47 | 55868.04 | 56079.54 |
| 总计 | 2239281.63 | 409696.92 | 5653667.97 | 453302.19 | 6020068.59 | 166795.29 | 14942812.59 |
Tab. 4
Impact of climate change on annual PET for land use types on the northern slope of Tianshan Mountains during various periods from 2000 to 2021 /mm"
| 土地利 用类型 | 年份 | PET起始值 | PET结束值 | PET变化量 |
|---|---|---|---|---|
| 耕地 | 2000—2004 | 939.92 | 950.22 | 10.30 |
| 2004—2008 | 951.18 | 978.71 | 27.53 | |
| 2008—2012 | 981.94 | 950.26 | -31.68 | |
| 2012—2016 | 954.18 | 965.91 | 11.73 | |
| 2016—2021 | 967.11 | 992.19 | 25.08 | |
| 草地 | 2000—2004 | 802.11 | 812.71 | 10.60 |
| 2004—2008 | 815.10 | 838.72 | 23.62 | |
| 2008—2012 | 831.47 | 799.90 | -31.57 | |
| 2012—2016 | 794.38 | 811.31 | 16.93 | |
| 2016—2021 | 807.27 | 828.13 | 20.86 | |
| 未利用地 | 2000—2004 | 986.76 | 988.32 | 1.56 |
| 2004—2008 | 987.14 | 1017.19 | 30.06 | |
| 2008—2012 | 1018.98 | 975.26 | -43.71 | |
| 2012—2016 | 979.43 | 1005.21 | 25.78 | |
| 2016—2021 | 1000.87 | 1024.18 | 23.32 |
Tab. 5
Influence rate of different factors on PET on the northern slope of Tianshan Mountains /%"
| 年份 | 草地变化为耕地 | 未利用地变化为耕地 | |||
|---|---|---|---|---|---|
| 气候变化 | 土地利用 类型变化 | 气候变化 | 土地利用 类型变化 | ||
| 2000—2004 | 89.60 | 10.40 | 58.65 | 41.35 | |
| 2004—2008 | 83.37 | 16.63 | 68.74 | 31.26 | |
| 2008—2012 | 99.43 | 0.57 | 92.65 | 7.35 | |
| 2012—2016 | 84.99 | 15.01 | 61.28 | 38.72 | |
| 2016—2021 | 85.14 | 14.86 | 84.34 | 15.66 | |
| 2000—2021 | 88.51 | 11.38 | 73.13 | 26.87 | |
| [1] |
祁添垚, 张强, 王月, 等. 1960—2005年中国蒸发皿蒸发量变化趋势及其影响因素分析[J]. 地理科学, 2015, 35(12): 1599-1606.
doi: 10.13249/j.cnki.sgs.2015.012.1599 |
|
[Qi Tianyao, Zhang Qiang, Wang Yue, et al. Spatiotemporal patterns of pan evaporation in 1960—2005 in China: Changing properties and possible causes[J]. Scientia Geographica Sinica, 2015, 35(12): 1599-1606. ]
doi: 10.13249/j.cnki.sgs.2015.012.1599 |
|
| [2] | Gao G, Chen D L, Ren G Y, et al. Trend of potential evapotranspiration over China during 1956 to 2000[J]. Geographical Research, 2006, 25(3): 378-387. |
| [3] |
郭宝, 刘梅先, 杜虎, 等. 亚热带典型森林下垫面大气层结变化规律及其对潜在蒸散发估算的影响[J]. 地理科学, 2024, 44(2): 359-367.
doi: 10.13249/j.cnki.sgs.20221584 |
|
[Guo Bao, Liu Meixian, Du Hu, et al. Variation of atmospheric stability in a typical subtropical forest and its effects on potential evapotranspiration[J]. Scientia Geographica Sinica, 2024, 44(2): 359-367. ]
doi: 10.13249/j.cnki.sgs.20221584 |
|
| [4] | 赵亚迪, 刘永和, 李建林, 等. 1960—2013年中国地表潜在蒸散发时空变化及其对气象因子的敏感性[J]. 沙漠与绿洲气象, 2018, 12(3): 1-9. |
| [Zhao Yadi, Liu Yonghe, Li Jianlin, et al. Spatial and temporal variation of potential evapotranspiration and its sensitivity to meteorological factors in China from 1960 to 2013[J]. Desert and Oasis Meteorology, 2018, 12(3): 1-9. ] | |
| [5] | 阴晓伟, 吴一平, 赵文智, 等. 西北旱区潜在蒸散发的气候敏感性及其干旱特征研究[J]. 水文地质工程地质, 2021, 48(3): 20-30. |
| [Yin Xiaowei, Wu Yiping, Zhao Wenzhi, et al. Drought characteristics and sensitivity of potential evapotranspiration to climatic factors in the arid and semi-arid areas of northwest China[J]. Hydrogeology and Engineering Geology, 2021, 48(3): 20-30. ] | |
| [6] | 刘文辉, 张宝忠, 魏征, 等. 不同气候区潜在蒸散量变化趋势及归因分析[J]. 中国农业气象, 2023, 44(7): 545-559. |
| [Liu Wenhui, Zhang Baozhong, Wei Zheng, et al. Variation trend and attribution analysis of potential evapotranspiration in different climate regions[J]. Chinese Journal of Agrometeorology, 2023, 44(7): 545-559. ] | |
| [7] | 石欣荣, 佘敦先, 夏军, 等. 1960—2019年三北地区潜在蒸散发的变化及归因[J]. 武汉大学学报(工学版), 2022, 55(10): 973-984. |
| [Shi Xinrong, She Dunxian, Xia Jun, et al. Variation and attribution of potential evapotranspiration in the Three-Northern Regi- ons, China during 1960—2019[J]. Engineering Journal of Wuhan University, 2022, 55(10): 973-984. ] | |
| [8] | 杨海昌, 张凤华, 王东方, 等. 近60年玛河流域绿洲蒸散量变化趋势及其影响因素分析[J]. 干旱区资源与环境, 2014, 28(7): 18-23. |
| [Yang Haichang, Zhang Fenghua, Wang Dongfang, et al. The analysis of the variation trend and influencing factors of evapotranspiration in oasis along Manas River valley in the last 60 years[J]. Journal of Arid Land Resources and Environment, 2014, 28(7): 18-23. ] | |
| [9] | 黄会平, 曹明明, 宋进喜, 等. 1957—2012年中国参考作物蒸散量时空变化及其影响因子分析[J]. 自然资源学报, 2015, 30(2): 315-326. |
| [Huang Huiping, Cao Mingming, Song Jinxi, et al. Temporal and spatial changes of potential evapotranspiration and its influencing factors in China from 1957 to 2012[J]. Journal of Natural Resources, 2015, 30(2): 315-326. ] | |
| [10] |
孙金容, 李兴, 魏敬铤. 近40 a流域气候变化与人类活动双重驱动下乌梁素海面积变化特征研究[J]. 干旱区地理, 2024, 47(10): 1688-1699.
doi: 10.12118/j.issn.1000-6060.2023.734 |
|
[Sun Jinrong, Li Xing, Wei Jingting. Area change characteristics of Wuliangsuhai Lake driven by climate change and human activities in the basin in the past 40 years[J]. Arid Land Geography, 2024, 47(10): 1688-1699. ]
doi: 10.12118/j.issn.1000-6060.2023.734 |
|
| [11] |
马亚丽, 牛最荣, 孙栋元. 河西走廊潜在蒸散发时空格局变化与气象因素的关系[J]. 干旱区地理, 2024, 47(2): 192-202.
doi: 10.12118/j.issn.1000-6060.2023.108 |
|
[Ma Yali, Niu Zuirong, Sun Dongyuan. Relationship between changes in spatial and temporal patterns of potential evapotranspiration and meteorological factors in the Hexi Corridor[J]. Arid Land Geography, 2024, 47(2): 192-202. ]
doi: 10.12118/j.issn.1000-6060.2023.108 |
|
| [12] | 周正模, 杜付然, 江海涛, 等. 淮河上游土地利用变化对流域蒸散发能力影响研究[J]. 中国农村水利水电, 2018(1): 60-65, 70. |
| [Zhou Zhengmo, Du Furan, Jiang Haitao, et al. Research on the impact of land use change on potential evapotranspiration in the upper Huaihe Basin[J]. China Rural Water and Hydropower, 2018(1): 60-65, 70. ] | |
| [13] | 吕忠杰, 刘海世, 张福存, 等. 25年来额济纳天然绿洲LUCC、ET与VC研究[J]. 干旱区资源与环境, 2014, 28(5): 53-59. |
| [Lü Zhongjie, Liu Haishi, Zhang Fucun, et al. LUCC, ET and VC study on Ejina natural oasis over 25 years[J]. Journal of Arid Land Resources and Environment, 2014, 28(5): 53-59. | |
| [14] | Han S J, Tang Q H, Zhang X Z, et al. Surface wind observations affected by agricultural development over northwest China[J]. Environmental Research Letters, 2016, 11(5): 054014, doi: 10.1088/1748-9326/11/5/054014. |
| [15] |
宋文杰, 张清, 刘莎莎, 等. 基于LUCC的干旱区人为干扰与生态安全分析——以天山北坡经济带绿洲为例[J]. 干旱区研究, 2018, 35(1): 235-242.
doi: 10.13866/j.azr.2018.01.29 |
|
[Song Wenjie, Zhang Qing, Liu Shasha, et al. LUCC-based human disturbance and ecological security in arid area: A case study in the economic zone on northern slope of theTianshan Mountains[J]. Arid Zone Research, 2018, 35(1): 235-242. ]
doi: 10.13866/j.azr.2018.01.29 |
|
| [16] |
陈乐, 程勇翔, 王江丽. 1990—2020年天山北坡经济带耕地时空动态变化的分析[J]. 石河子大学学报(自然科学版), 2022, 40(2): 223-230.
doi: 10.13880/j.cnki.65-1174/n.2021.21.052 |
| [Chen Le, Cheng Yongxiang, Wang Jiangli. Analysis of temporal and spatial dynamic changes of farmland in north slope economic zone of Tianshan Mountain from 1990 to 2020[J]. Journal of Shihezi University (Natural Science Edition), 2022, 40(2): 223-230. ] | |
| [17] | 孙智斌, 高敏华, 崔雪锋. 基于遥感与GIS的天山北坡经济带2000—2015年土地利用动态变化研究[J]. 北京师范大学学报(自然科学版), 2018, 54(3): 397-404. |
| [Sun Zhibin, Gao Minhua, Cui Xuefeng. Land use change in north slope economic zone of Tianshan Mountain based on remote sensing and GIS from 2000 to 2015[J]. Journal of Beijing Normal University (Natural Science Edition), 2018, 54(3): 397-404. ] | |
| [18] | 齐亚霄, 张飞, 陈瑞, 等. 2001—2015年天山北坡植被覆盖动态变化研究[J]. 生态学报, 2020, 40(11): 3677-3687. |
| [Qi Yaxiao, Zhang Fei, Chen Rui, et al. Vegetation coverage dynamics in northern slope of Tianshan Mountains from 2001 to 2015[J]. Acta Ecologica Sinica, 2020, 40(11): 3677-3687. ] | |
| [19] | 李艳菊, 丁建丽, 张钧泳, 等. 2001—2015年天山北坡植被覆盖对干旱的响应——基于土地利用/土地覆盖分析[J]. 生态学报, 2019, 39(17): 6206-6217. |
| [Li Yanju, Ding Jianli, Zhang Junyong, et al. Response of vegetation cover to drought in the northern slope of the Tianshan Mountains during 2001—2015: Based on the land-use and land-cover change[J]. Acta Ecologica Sinica, 2019, 39(17): 6206-6217. ] | |
| [20] |
王宗侠, 刘苏峡. 1990—2020年天山北坡地下水储量估算及其时空演变规律[J]. 地理学报, 2023, 78(7): 1744-1763.
doi: 10.11821/dlxb202307014 |
|
[Wang Zongxia, Liu Suxia. Estimation and spatiotemporal evolution of groundwater storage on the northern slope of the Tianshan Mountains over the past three decades[J]. Acta Geographica Sinica, 2023, 78(7): 1744-1763. ]
doi: 10.11821/dlxb202307014 |
|
| [21] |
张巧凤, 刘桂香, 于红博, 等. 基于MOD16A2的锡林郭勒草原近14年的蒸散发时空动态[J]. 草地学报, 2016, 24(2): 286-293.
doi: 10.11733/j.issn.1007-0435.2016.02.007 |
|
[Zhang Qiaofeng, Liu Guixiang, Yu Hongbo, et al. Temporal and spatial dynamic of ET based on MOD16A2 in recent fourteen years in Xilingol steppe[J]. Acta Agrestia Sinica, 2016, 24(2): 286-293. ]
doi: 10.11733/j.issn.1007-0435.2016.02.007 |
|
| [22] | 陈耀亮. 干旱区内陆河流域土地利用/土地覆被变化及其对蒸散发的影响[D]. 杭州: 浙江大学, 2018. |
| [Chen Yaoliang. Land use/land cover change in inland river basins in arid regions and their impact on evapotranspiration[D]. Hangzhou: Zhejiang University, 2018. ] | |
| [23] |
艳燕, 张弛, 匡文慧, 等. 天山北坡城市群非渗透面下的土壤有机碳特征[J]. 地理科学进展, 2015, 34(6): 781-789.
doi: 10.18306/dlkxjz.2015.06.013 |
|
[Yan Yan, Zhang Chi, Kuang Wenhui, et al. Orgnic carbon charasteristics of soils beneath urban impervious surface in northern Tianshan urban cluster[J]. Progress in Geography, 2015, 34(6): 781-789. ]
doi: 10.18306/dlkxjz.2015.06.013 |
|
| [24] | 赵会顺, 陈超, 胡振琪, 等. 天山北坡经济带城市土地集约利用评价及障碍因素分析[J]. 农业工程学报, 2018, 34(20): 258-266. |
| [Zhao Huishun, Chen Chao, Hu Zhenqi, et al. Evaluation of intensive urban land use and analysis of obstacle factors in northern slope of Tianshan Mountains[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2018, 34(20): 258-266. ] | |
| [25] | 赵永玉, 阿里木江·卡斯木, 高鹏文, 等. 基于GIS的天山北坡城市群人居环境自然适宜性评价[J]. 生态科学, 2023, 42(5): 84-93. |
| [Zhao Yongyu, Kasim Alimujiang, Gao Pengwen, et al. Evaluation of natural suitability of human settlements in urban agglomeration on the northern slope of Tianshan Mountain based on GIS[J]. Ecological Science, 2023, 42(5): 84-93. ] | |
| [26] |
Peng S Z, Ding Y X, Liu W Z, et al. 1 km monthly temperature and precipitation dataset for China from 1901 to 2017[J]. Earth System Science Data, 2019, 11: 1931-1946.
doi: 10.5194/essd-11-1931-2019 |
| [27] |
Peng S Z, Ding Y X, Wen Z M, et al. Spatiotemporal change and trend analysis of potential evapotranspiration over the Loess Plateau of China during 2011—2100[J]. Agricultural and Forest Meteorology, 2017, 233: 183-194.
doi: 10.1016/j.agrformet.2016.11.129 |
| [28] | Ding Y X, Peng S Z. Spatiotemporal trends and attribution of drought across China from 1901—2100[J]. Sustainability, 2020, 12: 477, doi: 10.3390/su12020477. |
| [29] |
Ding Y X, Peng S Z. Spatiotemporal change and attribution of potential evapotranspiration over China from 1901 to 2100[J]. Theoretical and Applied Climatology, 2021, 145: 79-94.
doi: 10.1007/s00704-021-03625-w |
| [30] |
Yang J, Huang X. The 30 m annual land cover dataset and its dynamics in China from 1990 to 2019[J]. Earth System Science Data, 2021, 13(8): 3907-3925.
doi: 10.5194/essd-13-3907-2021 |
| [31] | 汪攀, 刘毅敏. Sen’s斜率估计与Mann-Kendall法在设备运行趋势分析中的应用[J]. 武汉科技大学学报, 2014, 37(6): 454-457, 472. |
| [Wang Pan, Liu Yimin. Application of Sen’s slope estimation and Mann-Kendall method in the trend analysis of equipment operation[J]. Jouranl of Wuhan University of Science and Technology, 2014, 37(6): 454-457, 472. ] | |
| [32] | 杨铭珂, 贺中华, 任荣仪, 等. 黔中地区潜在蒸散发的时空变化及对土地利用变化的响应[J]. 水资源与水工程学报, 2021, 32(3): 106-117. |
| [Yang Mingke, He Zhonghua, Ren Rongyi, et al. Spatio-temporal variation of potential evapotranspiration and its response to land use change in central Guizhou[J]. Journal of Water Resources and Water Engineering, 2021, 32(3): 106-117. ] | |
| [33] | 刘粲. 黄土高原植被恢复对土壤水分的影响研究[D]. 石家庄: 河北地质大学, 2023. |
| [Liu Can. Study on the effect of vegetation restoration on soil moisture on the Loess Plateau[D]. Shijiazhuang: Hebei GEO University, 2023. ] | |
| [34] | 刘纪远, 布和敖斯尔. 中国土地利用变化现代过程时空特征的研究——基于卫星遥感数据[J]. 第四纪研究, 2000, 20(3): 229-239. |
| [Liu Jiyuan, Buheaosier. Study on spatial-temporal feature of modern landuse change in China: Using remote sensing techniques[J]. Quaternary Sciences, 2000, 20(3): 229-239. ] | |
| [35] | 王洁, 董刚, 张峰. 松嫩平原西部气候和土地利用变化对蒸散的影响[J]. 山西大学学报(自然科学版), 2015, 38(2): 375-384. |
| [Wang Jie, Dong Gang, Zhang Feng. Effects of climatic change and land use/cover change on evapotranspirationin the western Songnen Plain of northeast China[J]. Journal of Shanxi University (Natural Science Edition), 2015, 38(2): 375-384. ] | |
| [36] | 王祖方. 黑河绿洲土地利用格局变化及其对区域蒸散发的影响[D]. 武汉: 华中师范大学, 2015. |
| [Wang Zufang. Oasis land use pattern change and its effect on regional ET in the Heihe River Basin[D]. Wuhan: Central China Normal University, 2015. ] | |
| [37] |
姚俊强, 毛炜峄, 陈静, 等. 新疆气候“湿干转折”的信号和影响探讨[J]. 地理学报, 2021, 76(1): 57-72.
doi: 10.11821/dlxb202101005 |
|
[Yao Junqiang, Mao Weiyi, Chen Jing, et al. Signal and impact of wet-to-dry shift over Xinjiang, China[J]. Acta Geographica Sinica, 2021, 76(1): 57-72. ]
doi: 10.11821/dlxb202101005 |
|
| [38] | 梅静. 气候与植被变化对西北地区蒸散发影响评估[D]. 兰州: 西北师范大学, 2023. |
| [Mei Jing. Assessment of the impact of climate and vegetation change on evapotranspiration in northwest China[D]. Lanzhou: Northwest Normal University, 2023. ] | |
| [39] |
杨一飞, 杨鹏年, 汪昌树, 等. 新疆焉耆盆地农田耗水有效性评价[J]. 干旱区地理, 2023, 46(5): 730-741.
doi: 10.12118/j.issn.1000-6060.2022.405 |
|
[Yang Yifei, Yang Pengnian, Wang Changshu, et al. Effectiveness evaluation of water consumption in agricultural land of Yanqi Basin, Xinjiang[J]. Arid Land Geography, 2023, 46(5): 730-741. ]
doi: 10.12118/j.issn.1000-6060.2022.405 |
|
| [40] | 韩松俊, 胡和平, 杨大文, 等. 塔里木河流域山区和绿洲潜在蒸散发的不同变化及影响因素[J]. 中国科学(E辑: 技术科学), 2009, 39(8): 1375-1383. |
| [Han Songjun, Hu Heping, Yang Dawen, et al. Differences in changes of potential evaporation in the mountainous and oasis regions of the Tarim Basin, northwest China[J]. Science China Series E: Technological Sciences, 2009, 39(8): 1375-1383. ] |
|
||
