组态视角下新疆农业生产水足迹治理的多重路径

doi:10.12118/j.issn.1000-6060.2025.575

摘要/Abstract

摘要：

水资源对维系干旱区绿洲农业发展至关重要。针对新疆农业水资源结构性短缺与利用低效的复合困境，以2012—2024年新疆14个地州市为研究单元，测算棉花、玉米和小麦3种作物的生产水足迹，用对数平均迪氏指数分解法（LMDI）分解5类影响因子，动态定性比较分析（动态QCA）方法识别降低农业生产水足迹强度的组态路径及其时空异质性。结果表明：（1）全疆平均农业生产水足迹在时间上呈现先升后降的趋势，2016年达到峰值8.810 m³⋅kg^-1；空间上呈现东南高、西北低的分布格局，吐鲁番市均值高达25.609 m³⋅kg^-1，是阿勒泰地区的11.8倍。（2）技术进步、种植结构、节水效应、管理水平和农业经济发展水平是影响新疆农业生产水足迹强度的重要因素，并且有显著的动态演变特征。其中，管理水平与技术进步的驱动效应由局部正向逐渐演变为全域抑制。（3）降低新疆农业生产水足迹强度的等效路径分别为技术和种植结构双驱型、节水和管理协同型、技术主导型以及管理和种植结构双驱型。（4）所有组态均存在显著的空间异质性：农业基础较好的地区其组态路径显著多于薄弱地区。未来新疆需依据各地区的资源禀赋和发展阶段，对农业生产水足迹实施时空适配的治理策略。

关键词: 农业生产水足迹, LMDI模型, 动态QCA, 组态路径, 新疆

Abstract:

Water resources are crucial for the sustained development of oasis agriculture in arid regions. To resolve the complex dilemmas of structural shortages and inefficient use of agricultural water resources in Xinjiang, this study calculates the production water footprint of three crops (cotton, corn, and wheat) in 14 prefectures and cities in Xinjiang, China, from 2012 to 2024, identifies five types of influencing factors through the logarithmic mean Divisia index decomposition method, and identifies configurational paths for reducing the intensity of agricultural production water footprint and their spatiotemporal heterogeneity through dynamic qualitative comparative analysis (dynamic QCA). The results show that: (1) The average agricultural production water footprint across Xinjiang first increased and then decreased over time, reaching a peak of 8.810 m³·kg^-1 in 2016; spatially, it was higher in the southeast and lower in the northwest, with the average value in Turpan City as high as 25.609 m³·kg^-1, 11.8 times that of Altay Prefecture. (2) Technological progress, cropping structure, water-saving effects, management level, and agricultural economic development level are important factors in the intensity of agricultural production water footprint in Xinjiang and exhibit significant changes over time. In particular, the driving effects of management level and technological progress have gradually evolved from exerting partial positive effects to pan-regional inhibitory effects. (3) The equivalent paths for reducing the intensity of agricultural production water footprint in Xinjiang are the technology-cropping-structure dual-driving type, water-saving-management collaborative type, technology-led type, and management-cropping-structure dual-driving type. (4) All configurations demonstrate significant spatial heterogeneity: Regions with better agricultural foundations have significantly more configurational paths than those with weak foundations. In the future, spatiotemporally adaptive governance strategies based upon the resource endowments and development stages of each region should be implemented to reduce the agricultural production water footprint in Xinjiang.

Key words: agricultural production water footprint, LMDI model, dynamic QCA, configurational paths, Xinjiang

蒋志辉, 琚慧琦, 欧阳金琼, 苏旭峰. 组态视角下新疆农业生产水足迹治理的多重路径[J]. 干旱区地理, 2026, 49(9): 1951-1964.

JIANG Zhihui, JU Huiqi, OUYANG Jinqiong, SU Xufeng. Multiple paths for the governance of agricultural production water footprint in Xinjiang from the configurational perspective[J]. Arid Land Geography, 2026, 49(9): 1951-1964.

图/表 14

图1

表1

图2

图3

表2

图4

表3

表4

表5

图5

表6

图6

图7

表7

参考文献 35

[1]	刘晓东, 彭晓彤, 白丽, 等. 水足迹视阈下河北省农业用水驱动因素分析[J]. 中国农业资源与区划, 2021, 42(11): 188-198.
	[Liu Xiaodong, Peng Xiaotong, Bai Li, et al. Study on driving factors of agricultural water in Hebei Province based on water footprint[J]. Chinese Journal of Agricultural Resources and Regional Planning, 2021, 42(11): 188-198.]
[2]	中华人民共和国水利部. 中国节约用水报告2024[EB/OL]. [2025-07-23]. https://qgjsb.mwr.gov.cn/zyzx/jsbg/202507/t20250723_1973935.html.
	[Ministry of Water Resources of the People’s Republic of China. China water conservation report in 2024[EB/OL]. [2025-07-23]. https://qgjsb.mwr.gov.cn/zyzx/jsbg/202507/t20250723_1973935.html.]
[3]	新疆维吾尔自治区人民政府. 新疆维吾尔自治区2024年国民经济和社会发展统计公报[EB/OL]. [2025-03-26]. https://www.xinjiang.gov.cn/xinjiang/tjgb/202503/f0578f74e4e04369af0ee82566586397.shtml.
	[People’s Government of the Xinjiang Uygur Autonomous Region. Statistical communique on national economic and social development of the Xinjiang Uygur Autonomous Region in 2024[EB/OL]. [2025-03-26]. https://www.xinjiang.gov.cn/xinjiang/tjgb/202503/f0578f74e4e04369af0ee82566586397.shtml.]
[4]	Mekonnen M M, Hoekstra A Y. The green, blue and grey water footprint of crops and derived crop products[J]. Hydrology and Earth System Sciences, 2011, 15(5): 1577-1600. doi: 10.5194/hess-15-1577-2011
[5]	闫晨健, 栗萌, 卓拉, 等. 1989-2019年陕西省作物生产水足迹时空演变与节水潜力评价[J]. 资源科学, 2023, 45(1): 158-173. doi: 10.18402/resci.2023.01.12
	[Yan Chenjian, Li Meng, Zhuo La, et al. Spatiotemporal evolution of water footprint and water-saving potentials of crop production in Shaanxi Province during 1989-2019[J]. Resources Science, 2023, 45(1): 158-173.] doi: 10.18402/resci.2023.01.12
[6]	Mekonnen M M, Hoekstra A Y. Blue water footprint linked to national consumption and international trade is unsustainable[J]. Nature Food, 2020, 1(12): 792-800. doi: 10.1038/s43016-020-00198-1 pmid: 37128061
[7]	江激宇, 刘嘉铭, 张士云. 淮河流域谷物生产水足迹及用水效率研究[J]. 农业资源与环境学报, 2024, 41(2): 371-382.
	[Jiang Jiyu, Liu Jiaming, Zhang Shiyun. Study on the water footprint and water efficiency of cereal production in the Huai River Basin[J]. Journal of Agricultural Resources and Environment, 2024, 41(2): 371-382.]
[8]	王思雨. 基于水足迹的中型灌区种植结构优化研究——以三刘寨灌区为例[D]. 郑州: 华北水利水电大学, 2023.
	[Wang Siyu. Optimization of planting structure in medium-sized irrigation areas based on water footprint: Take Sanliuzhai irrigation district as an example[D]. Zhengzhou: North China University of Water Resources and Electric Power, 2023.]
[9]	罗静怡, 东梅. 干旱区粮食生产用水驱动力解析与节水潜力评价——以宁夏为例[J/OL]. 中国农业资源与区划. [2025-08-18]. https://link.cnki.net/urlid/11.3513.S.20250818.1147.012.
	[Luo Jingyi, Dong Mei. Analysis of driving forces of water use in grain production and evaluation of water-saving potential in dryland: A case study of Ningxia[J/OL]. Chinese Journal of Agricultural Resources and Regional Planning. [2025-08-18]. https://link.cnki.net/urlid/11.3513.S.20250818.1147.012.]
[10]	黄会平, 张冰, 李新生, 等. 海河流域农业水足迹分布及对气候变化的响应[J]. 人民黄河, 2019, 41(2): 64-75.
	[Huang Huiping, Zhang Bing, Li Xinsheng, et al. Spatial-temporal characteristics agricultural water footprint in Haihe River Basin and its response to climate change[J]. Yellow River, 2019, 41(2): 64-75.]
[11]	李曼, 何巧凤, 刘焕才. 疏勒河流域中下游地区主要粮食作物生产水足迹变化及影响因素分析[J]. 节水灌溉, 2020(9): 94-105.
	[Li Man, He Qiaofeng, Liu Huancai. Analysis of water footprint changes and influencing factors of main grain crops in the middle and lower reaches of the Shule River Basin[J]. Water Saving Irrigation, 2020(9): 94-105.]
[12]	Zeng W, He J C, Qiu Y L, et al. Unravelling the temporal-spatial distribution of the agricultural water footprint in the Yangtze River Basin (YRB) of China[J]. Water, 2021, 13(18): 25-62. doi: 10.3390/w13010025
[13]	王倩, 黄凯. 基于系统动力学的北京市农业水足迹模拟与影响因素分析[J]. 系统工程, 2021, 39(3): 13-24.
	[Wang Qian, Huang Kai. Simulation of agricultural water footprint and analysis of influencing factors in Beijing based on system dynamic[J]. Systems Engineering, 2021, 39(3): 13-24.]
[14]	郭相平, 高爽, 吴梦洋, 等. 中国农作物水足迹时空分布与影响因素分析[J]. 农业机械学报, 2018, 49(5): 295-302.
	[Guo Xiangping, Gao Shuang, Wu Mengyang, et al. Analysis of temporal-spatial distribution and influencing factors of water footprint in crop production system of China[J]. Transactions of the Chinese Society for Agricultural Machinery, 2018, 49(5): 295-302.]
[15]	金谦, 桂东伟, 高霄鹏, 等. 新疆主要农作物生产水足迹研究[J]. 干旱地区农业研究, 2018, 36(6): 243-249.
	[Jin Qian, Gui Dongwei, Gao Xiaopeng, et al. Water footprints of primary crop production in Xinjiang[J]. Agricultural Research in the Arid Areas, 2018, 36(6): 243-249.]
[16]	蒙克, 魏必. 反思qca方法的“时间盲区”: 为公共管理研究找回“时间”[J]. 中国行政管理, 2023(1): 96-104.
	[Meng Ke, Wei Bi. Rethinking the “time blindness” of the qualitative comparative analysis: Bringing back “time” for public management research[J]. Chinese Administration Society, 2023(1): 96-104.]
[17]	张沛, 龙爱华, 海洋, 等. 1988-2015年新疆农业用水时空变化与政策驱动研究——基于农作物水足迹的统计分析[J]. 冰川冻土, 2021, 43(1): 242-253. doi: 10.7522/j.issn.1000-0240.2018.1058
	[Zhang Pei, Long Aihua, Hai Yang, et al. Spatiotemporal variations and driving forces of agricultural water consumption in Xinjiang during 1988-2015: Based on statistical analysis of crop water footprint[J]. Journal of Glaciology and Geocryology, 2021, 43(1): 242-253.]
[18]	新疆维吾尔自治区水利厅. 水利厅加快推进新疆“十五五”水安全保障规划编制工作[EB/OL]. [2025-06-13]. https://slt.xinjiang.gov.cn/xjslt/c114428/202506/39344aa2b4fe482d9be0ed7ea4363e79.shtml.
	[Water Resources Department of the Xinjiang Uygur Autonomous Region. The department accelerates the formulation of Xinjiang’s 15^th Five-Year Plan for water security guarantee[EB/OL]. [2025-06-13]. https://slt.xinjiang.gov.cn/xjslt/c114428/202506/39344aa2b4fe482d9be0ed7ea4363e79.shtml.]
[19]	国家气象信息中心. 中国地面气象观测数据[EB/OL]. [2025-09-13]. https://data.cma.cn/data/detail/dataCode/A.0012.0001.S011.html.
	[National Meteorological Information Center. China surface meteorological observation data[EB/OL]. [2025-09-13]. https://data.cma.cn/data/detail/dataCode/A.0012.0001.S011.html.]
[20]	新疆维吾尔自治区统计局. 新疆统计年鉴[DB/OL]. [2025-09-13]. https://tjj.xinjiang.gov.cn/tjj/tjfw/list_tjfw.shtml.
	[Statistics Bureau of the Xinjiang Uygur Autonomous Region. Xinjiang statistical yearbook[DB/OL]. [2025-09-13]. https://tjj.xinjiang.gov.cn/tjj/tjfw/list_tjfw.shtml.]
[21]	何旭刚, 买买提·沙吾提, 夏梓洋, 等. 1960-2020年新疆主要作物需水量时空特征分析[J]. 作物学报, 2023, 49(12): 3352-3363. doi: 10.3724/SP.J.1006.2023.31007
	[He Xugang, Shawuti Memet, Xia Ziyang, et al. Spatio-temporal characteristics of water requirement of main crops in Xinjiang from 1960 to 2020[J]. Acta Agronomica Sinica, 2023, 49(12): 3352-3363.] doi: 10.3724/SP.J.1006.2023.31007
[22]	郑永丹. 中国主要粮食作物生育期时空格局及其变化[D]. 武汉: 华中师范大学, 2016.
	[Zheng Yongdan. Research on the spatial-temporal distribution of the growth period of main grain crops and its change in China[D]. Wuhan: Central China Normal University, 2016.]
[23]	林馨园, 许峰, 马学花, 等. 1990-2020年塔里木河流域五地州不同作物生产与种植结构的分析与评价——基于水足迹的视角[J]. 中国农业资源与区划, 2024, 45(9): 196-205.
	[Lin Xinyuan, Xu Feng, Ma Xuehua, et al. Analysis and evaluation of different crop production and planting structure in five prefectures of Tarim River Basin from 1990 to 2020: Based on water footprint[J]. Chinese Journal of Agricultural Resources and Regional Planning, 2024, 45(9): 196-205.]
[24]	中华人民共和国生态环境部. 地表水环境质量标准[EB/OL]. [2002-06-01]. https://www.mee.gov.cn/ywgz/fgbz/bz/bzwb/shjbh/shjzlbz/200206/t20020601_66497.shtml.
	[Ministry of Ecology and Environment of the People’s Republic of China. Environmental quality standard for surface water[EB/OL]. [2002-06-01]. https://www.mee.gov.cn/ywgz/fgbz/bz/bzwb/shjbh/shjzlbz/200206/t20020601_66497.shtml.]
[25]	徐依婷, 穆月英. 粮食生产水足迹动态演变及分解效应[J]. 华南农业大学学报(社会科学版), 2020, 19(3): 70-83.
	[Xu Yiting, Mu Yueying. Dynamic change and decomposition effects of water footprint in grain production[J]. Journal of South China Agricultural University (Social Science Edition), 2020, 19(3): 70-83.]
[26]	尹朝静, 廖培森, 葛静芳, 等. 中国农业全要素水资源绿色生产率的区域差异、动态演进及收敛性[J]. 干旱区资源与环境, 2025, 39(2): 107-116.
	[Yin Chaojing, Liao Peisen, Ge Jingfang, et al. Regional differences, dynamic evolution and convergence of agricultural total factor water green productivity in China[J]. Journal of Arid Land Resources and Environment, 2025, 39(2): 107-116.]
[27]	吴志旻, 刘静. 不同小型农田水利设施管护模式对水稻生产率的影响研究[J]. 农业技术经济, 2025(10): 91-111.
	[Wu Zhimin, Liu Jing. The impact of different maintenance modes of small-scale farmland water conservancy facilities on rice productivity[J]. Journal of Agrotechnical Economics, 2025(10): 91-111.
[28]	刘继龙, 吴耀宇, 曹晓强, 等. 三江平原地区农作物水足迹时空演变特征及可持续性利用评价[J]. 东北农业大学学报, 2023, 54(8): 68-78.
	[Liu Jilong, Wu Yaoyu, Cao Xiaoqiang, et al. Temporal and spatial evolution characteristics of agricultural water footprint of crops in the Sanjiang Plain and evaluation on sustainable utilization[J]. Journal of Northeast Agricultural University, 2023, 54(8): 68-78.]
[29]	Fiss P C. Building better causal theories: A fuzzy set approach to typologies in organization research[J]. Academy of Management Journal, 2011, 54(2): 393-420. doi: 10.5465/amj.2011.60263120
[30]	杜运周, 刘秋辰, 程建青. 什么样的营商环境生态产生城市高创业活跃度?--基于制度组态的分析[J]. 管理世界, 2020, 36(9): 141-155.
	[Du Yunzhou, Liu Qiuchen, Cheng Jianqing. What kind of business environment ecology generates high urban entrepreneurial activity? An analysis based on institutional configuration[J]. Journal of Management World, 2020, 36(9): 141-155.]
[31]	张放. 影响地方政府信息公开的因素——基于省域面板数据的动态QCA分析[J]. 情报杂志, 2023, 42(1): 133-141.
	[Zhang Fang. Determinants of local governments’ information disclosure: A dynamic QCA analysis based on provincial panel data[J]. Journal of Intelligence, 2023, 42(1): 133-141.]
[32]	中华人民共和国农业农村部. 国家发布2014年棉花目标价格[EB/OL]. [2014-04-05]. https://www.moa.gov.cn/xw/zwdt/201404/t20140405_3841790.htm.
	[Ministry of Agriculture and Rural Affairs of the People’s Republic of China. The state issued the 2014 target price for cotton[EB/OL]. [2014-04-05]. https://www.moa.gov.cn/xw/zwdt/201404/t20140405_3841790.htm.]
[33]	杨巨星, 孙慧, 周晋楠, 等. 中国资源型城市转型脱碳时空演进及路径选择[J]. 干旱区地理, 2026, 49(1): 151-163. doi: 10.12118/j.issn.1000-6060.2024.743
	[Yang Juxing, Sun Hui, Zhou Jinnan, et al. Spatio-temporal evolution and pathway selection of transformation decarbonization in China’s resource-based cities[J]. Arid Land Geography, 2026, 49(1): 151-163.] doi: 10.12118/j.issn.1000-6060.2024.743
[34]	程鹏, 彭海洋, 侯丁榕, 等. 黄河流域农业灰水足迹强度空间格局及演进趋势[J]. 干旱区地理, 2025, 48(7): 1185-1197. doi: 10.12118/j.issn.1000-6060.2024.473
	[Cheng Peng, Peng Haiyang, Hou Dingrong, et al. Spatial pattern and evolution trend of agricultural grey water footprint intensity in the Yellow River Basin[J]. Arid Land Geography, 2025, 48(7): 1185-1197.] doi: 10.12118/j.issn.1000-6060.2024.473
[35]	褚家琦, 蒋志辉. 新疆农业水资源绿色效率时空演变及影响因素研究[J]. 干旱区地理, 2024, 47(7): 1231-1241. doi: 10.12118/j.issn.1000-6060.2023.577
	[Chu Jiaqi, Jiang Zhihui. Spatiotemporal evolution and influencing factors of green efficiency of agricultural water resources in Xinjiang[J]. Arid Land Geography, 2024, 47(7): 1231-1241.] doi: 10.12118/j.issn.1000-6060.2023.577

作物	区域	开始生长日期（月-日）	结束生长日期（月-日）	平均作物系数^[21]	生育期天数^[22]
棉花	北疆	04-30	10-09	0.64	162
	南疆	04-11	10-15	0.64	187
	东疆	04-10	10-07	0.64	180
冬小麦	南疆	09-11	07-10	0.43	300
春小麦	北疆	04-01	07-21	0.53	111
小麦	东疆	04-01	07-21	0.53	111
玉米	全疆	04-21	09-11	0.57	143

因素	贡献度
因素	2012—2015年	2016—2020年	2021—2024年
技术进步效应	-0.037	0.109	-4.456
种植结构效应	-0.023	0.051	-0.267
节水效应	0.059	-0.176	3.330
管理水平效应	0.021	0.104	-1.001
农业经济发展水平	0.006	-0.173	1.029

变量名称		指标	校准			描述性分析
变量名称		指标	完全隶属	交叉点	完全不隶属	均值	标准差	最大值	最小值
结果变量	生产水足迹强度	Y	0.022	0.057	0.483	0.225	0.405	2.485	0.015
条件变量	技术水平	X₁	-1.399	-0.134	1.199	-0.084	1.402	7.900	-3.789
	种植结构	X₂	-1.152	-0.012	1.615	0.066	1.342	4.034	-5.966
	节水效应	X₃	-1.663	0.062	1.376	-0.066	1.465	3.945	-5.532
	管理水平	X₄	-1.108	0.119	1.192	0.092	0.965	2.236	-4.018
	农业经济发展水平	X₅	-1.279	-0.262	0.878	-0.333	1.311	1.937	-12.414

前因条件	低生产水足迹强度				高生产水足迹强度
前因条件	汇总一致性	汇总覆盖度	组间一致性调整距离	组内一致性调整距离	汇总一致性	汇总覆盖度	组间一致性调整距离	组内一致性调整距离
X₁	0.615	0.654	0.265	0.244	0.604	0.572	0.397	0.307
~X₁	0.598	0.629	0.269	0.236	0.636	0.595	0.374	0.297
X₂	0.626	0.672	0.327	0.253	0.589	0.564	0.296	0.297
~X₂	0.594	0.618	0.386	0.253	0.658	0.610	0.288	0.230
X₃	0.586	0.612	0.389	0.265	0.665	0.618	0.257	0.283
~X₃	0.634	0.680	0.389	0.282	0.582	0.556	0.350	0.295
X₄	0.617	0.676	0.222	0.277	0.590	0.577	0.249	0.303
~X₄	0.614	0.627	0.269	0.261	0.668	0.608	0.226	0.242
X₅	0.599	0.630	0.405	0.207	0.627	0.588	0.483	0.299
~X₅	0.609	0.647	0.393	0.261	0.605	0.573	0.456	0.291

因果组合	指标	2013年	2014年	2015年	2016年	2017年	2018年	2019年	2020年	2021年	2022年	2023年	2024年
X₁/Y	一致性	0.72	0.82	0.52	0.51	0.75	0.33	0.45	0.56	0.53	0.72	0.76	0.70
X₁/Y	覆盖度	0.63	0.56	0.79	0.59	0.56	0.93	0.92	0.63	0.64	0.68	0.63	0.68
~X₁/Y	一致性	0.58	0.48	0.74	0.72	0.56	0.90	0.73	0.60	0.65	0.47	0.38	0.45
~X₁/Y	覆盖度	0.55	0.69	0.55	0.63	0.55	0.54	0.51	0.66	0.75	0.74	0.97	0.79
X₂/Y	一致性	0.80	0.27	0.97	0.54	0.43	0.52	0.51	0.74	0.77	0.54	0.71	0.64
X₂/Y	覆盖度	0.63	0.52	0.54	0.64	0.59	0.61	0.62	0.68	0.76	0.72	0.94	0.80
~X₂/Y	一致性	0.60	0.97	0.20	0.64	0.89	0.75	0.75	0.43	0.40	0.65	0.46	0.55
~X₂/Y	覆盖度	0.64	0.58	0.93	0.55	0.55	0.64	0.67	0.60	0.59	0.70	0.55	0.69
X₃/Y	一致性	0.60	0.64	0.47	0.93	0.78	0.96	0.82	0.45	0.45	0.46	0.31	0.40
X₃/Y	覆盖度	0.65	0.59	0.56	0.55	0.53	0.57	0.62	0.56	0.77	0.72	0.72	0.78
~X₃/Y	一致性	0.82	0.71	0.80	0.19	0.56	0.25	0.39	0.69	0.73	0.73	0.86	0.78
~X₃/Y	覆盖度	0.64	0.66	0.69	0.57	0.64	0.77	0.63	0.69	0.66	0.69	0.73	0.71
X₄/Y	一致性	0.78	0.80	0.43	0.45	0.52	0.47	0.58	0.61	0.64	0.70	0.70	0.68
X₄/Y	覆盖度	0.65	0.55	0.70	0.84	0.60	0.72	0.64	0.68	0.71	0.67	0.72	0.74
~X₄/Y	一致性	0.64	0.40	0.79	0.81	0.79	0.84	0.67	0.58	0.53	0.46	0.45	0.53
~X₄/Y	覆盖度	0.65	0.56	0.57	0.55	0.53	0.62	0.66	0.65	0.67	0.71	0.72	0.78
X₅/Y	一致性	0.63	0.33	0.73	0.55	0.35	0.89	0.73	0.79	0.87	0.53	0.62	0.17
X₅/Y	覆盖度	0.58	0.62	0.57	0.59	0.90	0.56	0.52	0.66	0.63	0.79	0.73	1.00
~X₅/Y	一致性	0.74	0.93	0.56	0.71	0.88	0.33	0.52	0.40	0.24	0.65	0.56	0.90
~X₅/Y	覆盖度	0.67	0.57	0.78	0.67	0.45	0.78	0.97	0.66	0.75	0.64	0.73	0.63
