古尔班通古特沙漠土壤水分含量与地形-植被因子关系研究

doi:10.12118/j.issn.1000-6060.2025.595

摘要/Abstract

摘要：

土壤水分是水资源形成、转化和消耗过程中不可或缺的组成部分。以古尔班通古特沙漠固定、半固定和流动沙丘上的土壤水分含量（简称土壤水分）为研究对象，采用偏最小二乘结构方程模型（PLS-SEM）、随机森林模型及沙普利加性解释（SHAP）分析方法，研究了不同深度土壤水分与地形-植被因子之间的关系。结果表明：（1）除了半固定与流动沙丘上的中层土壤水分分布无显著差异外，研究区其他类型沙丘的土壤水分垂直分布均呈现显著差异。（2）结构方程模型结果显示，固定沙丘上地形因子高差和植被因子灌木多度对土壤水分影响最为突出，半固定沙丘上坡度和灌木盖度为主导因子，而流动沙丘地形-植被因子对土壤水分的影响不显著。（3）关键因子交互作用结果进一步显示固定沙丘中草本多度>300株·m^-2、灌木多度>2株·m^-2的组合可缓解水分胁迫；半固定沙丘中草本多度>200株·m^-2、灌木盖度>30%时，能减弱坡度对土壤水分的不利影响；流动沙丘需维持草本盖度>20%、生物量>10 g·m^-2以提升水分含量。研究结果可为荒漠化治理提供精细化管理策略。

关键词: 古尔班通古特沙漠, 土壤水分, 地形-植被因子, 偏最小二乘结构方程模型, 随机森林模型

Abstract:

Soil moisture forms an essential component in the formation, transformation, and consumption of water resources. This study investigates soil moisture in fixed, semifixed, and mobile dunes of the Gurbantunggut Desert in Xinjiang, China. The relationship between moisture at different soil depths and topography-vegetation factors was analyzed using partial least squares structural equation model (PLS-SEM), random forest model, and Shapley additive explanations (SHAP) value analysis. The results showed that: (1) Except for soil moisture in the middle layer of semifixed and mobile dunes, the vertical distribution of moisture among dune types varied significantly. (2) Structual equation model indicated that the topography factor—height difference and vegetation factor—shrub abundance—had the most pronounced impacts on soil moisture in fixed dunes; slope degree and shrub coverage were dominant factors in semifixed dunes, whereas topography and vegetation factors had relatively minor effects in mobile dunes. (3) The interaction among key factors revealed that in fixed dunes, a combination of herb and shrub abundance >300 plants·m^-2 and >2 plants·m^-2, respectively alleviated water stress; in semifixed dunes, >200 plants·m^-2 and >30%, respectively mitigated the adverse impacts of slope degree on soil moisture; in mobile dunes, maintaining herb coverage at >20% and biomass at >10 g·m^-2 was necessary to enhance soil moisture content. These findings can help formulate refined management strategies for desertification control.

Key words: Gurbantunggut Desert, soil moisture, topography-vegetation factors, partial least squares structural equation model, random forest model

张璐, 张定海, 杨甜, 丘月. 古尔班通古特沙漠土壤水分含量与地形-植被因子关系研究[J]. 干旱区地理, 2026, 49(9): 1777-1787.

ZHANG Lu, ZHANG Dinghai, YANG Tian, QIU Yue. Relationship between soil moisture content and topography-vegetation factors in the Gurbantunggut Desert[J]. Arid Land Geography, 2026, 49(9): 1777-1787.

图/表 11

表1

图1

表2

图2

图3

图4

表3

表4

图5

图6

图7

参考文献 52

[1]	董光荣, 吴波, 慈龙骏, 等. 我国荒漠化现状、成因与防治对策[J]. 中国沙漠, 1999, 19(4): 22-36.
	[Dong Guangrong, Wu Bo, Ci Longjun, et al. Present situation, cause and control way of desertification in China[J]. Journal of Desert Research, 1999, 19(4): 22-36.]
[2]	常学尚, 常国乔. 干旱半干旱区土壤水分研究进展[J]. 中国沙漠, 2021, 41(1): 156-163. doi: 10.7522/j.issn.1000-694X.2020.00067
	[Chang Xueshang, Chang Guoqiao. Advances in research and prospect on soil moisture in arid and semi-arid areas[J]. Journal of Desert Research, 2021, 41(1): 156-163.] doi: 10.7522/j.issn.1000-694X.2020.00067
[3]	李新荣, 张志山, 黄磊, 等. 我国沙区人工植被系统生态-水文过程和互馈机理研究评述[J]. 科学通报, 2013, 58(增刊1): 397-410.
	[Li Xinrong, Zhang Zhishan, Huang Lei, et al. Review of the ecohydrological processes and feedback mechanisms controlling sand-binding vegetation systems in sandy desert regions of China[J]. Chinese Science Bulletin, 2013, 58(Suppl. 1): 397-410.]
[4]	Li J R, Okin G S, Alvarez L, et al. Effects of wind erosion on the spatial heterogeneity of soil nutrients in two desert grassland communities[J]. Biogeochemistry, 2008, 88(1): 73-88. doi: 10.1007/s10533-008-9195-6
[5]	张定海, 李新荣, 张鹏. 生态水文阈值在中国沙区人工植被生态系统管理中的意义[J]. 中国沙漠, 2017, 37(4): 678-688. doi: 10.7522/j.issn.1000-694X.2016.00163
	[Zhang Dinghai, Li Xinrong, Zhang Peng. Significance of eco-hydrological threshold in artificial vegetation ecosystem management in China desert area[J]. Journal of Desert Research, 2017, 37(4): 678-688.] doi: 10.7522/j.issn.1000-694X.2016.00163
[6]	Cheng Y B, Yang W B, Zhan H B, et al. On the origin of deep soil water infiltration in the arid sandy region of China[J]. Water, 2020, 12(9): 2409, doi: 10.3390/w12092409.
[7]	Fang X N, Zhao W W, Wang L X, et al. Variations of deep soil moisture under different vegetation types and influencing factors in a watershed of the Loess Plateau, China[J]. Hydrology and Earth System Sciences, 2016, 20(8): 3309-3323. doi: 10.5194/hess-20-3309-2016
[8]	Bordoni M, Bittelli M, Valentino R, et al. Soil water content estimated by support vector machine for the assessment of shallow landslides triggering: The role of antecedent meteorological conditions[J]. Environmental Modeling & Assessment, 2018, 23(4): 333-352.
[9]	Moeslund J E, Arge L, Bøcher P K, et al. Topography as a driver of local terrestrial vascular plant diversity patterns[J]. Nordic Journal of Botany, 2013, 31(2): 129-144. doi: 10.1111/more.2013.31.issue-2
[10]	Schaefer M L, Bogacki W, Lopez C M L, et al. Influence of slope aspect and vegetation on the soil moisture response to snowmelt in the German Alps[J]. Hydrology, 2024, 11(7): 101, doi: 10.3390/hydrology11070101.
[11]	Caviedes-Voullième D, Ahmadinia E, Hinz C. Interactions of microtopography, slope and infiltration cause complex rainfall-runoff behavior at the hillslope scale for single rainfall events[J]. Water Resources Research, 2021, 57(7): e2020WR028127, doi: 10.1029/2020WR028127.
[12]	Yang J, El-Kassaby Y A, Guan W B. The effect of slope aspect on vegetation attributes in a mountainous dry valley, southwest China[J]. Scientific Reports, 2020, 10(1): 16465, doi: 10.1038/s41598-020-73496-0.
[13]	Demir G, Michalzik B, Filipzik J, et al. Spatial variation of grassland canopy affects soil wetting patterns and preferential flow[J]. Hydrological Processes, 2022, 36(12): e14760, doi: 10.1002/hyp.14760.
[14]	Cai G C, Vanderborght J, Couvreur V, et al. Parameterization of root water uptake models considering dynamic root distributions and water uptake compensation[J]. Vadose Zone Journal, 2018, 17(1): 1-21.
[15]	陈昌笃, 张立运, 胡文康. 古尔班通古特沙漠的沙地植物群落、区系及其分布的基本特征[J]. 植物生态学与地植物学丛刊, 1983, 7(2): 89-99.
	[Chen Changdu, Zhang Liyun, Hu Wenkang. The basic characteristics of plant communities, flora and their distribution in the sandy district of Grubantungut[J]. Chinese Journal of Plant Ecology, 1983, 7(2): 89-99.]
[16]	张立运, 陈昌笃. 论古尔班通古特沙漠植物多样性的一般特点[J]. 生态学报, 2002, 22(11): 1923-1932.
	[Zhang Liyun, Chen Changdu. On the general characteristics of plant diversity of Gurbantunggut Sandy Desert[J]. Acta Ecologica Sinica, 2002, 22(11): 1923-1932.]
[17]	Zhang D H, Zhao Y Y, Qi H D, et al. Effects of micro-topography and vegetation on soil moisture on fixed sand dunes in Tengger Desert, China[J]. Plants, 2024, 13(11): 1571, doi: 10.3390/PLANTS13111571.
[18]	孙琰蕙, 张定海, 张志山. 腾格里沙漠不同类型沙丘土壤水分含量与地形-植被因子关系研究[J]. 干旱区地理, 2022, 45(5): 1570-1578. doi: 10.12118/j.issn.1000-6060.2022.027
	[Sun Yanhui, Zhang Dinghai, Zhang Zhishan. Relationship between soil moisture content and topography-vegetation factors in different types of dunes in the Tengger Desert[J]. Arid Land Geography, 2022, 45(5): 1570-1578.] doi: 10.12118/j.issn.1000-6060.2022.027
[19]	Zhang Z S, Li X R, Liu L C, et al. Distribution, biomass, and dynamics of roots in a revegetated stand of Caragana korshinskii in the Tengger Desert, northwestern China[J]. Journal of Plant Research, 2009, 122(1): 109-119. doi: 10.1007/s10265-008-0196-2
[20]	Hair J F, Matthews L M, Matthews R L, et al. PLS-SEM or CB-SEM: Updated guidelines on which method to use[J]. International Journal of Multivariate Data Analysis, 2017, 1(2): 107-123. doi: 10.1504/IJMDA.2017.087624
[21]	Altman N, Krzywinski M. Ensemble methods: Bagging and random forests[J]. Nature Methods: Techniques for Life Scientists and Chemists, 2017, 14(10): 933-934.
[22]	González S, García S, del Ser J, et al. A practical tutorial on bagging and boosting based ensembles for machine learning: Algorithms, software tools, performance study, practical perspectives and opportunities[J]. Information Fusion, 2020, 64: 205-237. doi: 10.1016/j.inffus.2020.07.007
[23]	Rudin C. Stop explaining black box machine learning models for high stakes decisions and use interpretable models instead[J]. Nature Machine Intelligence, 2019, 1(5): 206-215. doi: 10.1038/s42256-019-0048-x pmid: 35603010
[24]	Zhao R M, Hui R, Liu L C, et al. Effects of snowfall depth on soil physical-chemical properties and soil microbial biomass in moss-dominated crusts in the Gurbantunggut Desert, northern China[J]. Catena, 2018, 169: 175-182. doi: 10.1016/j.catena.2018.05.042
[25]	Yang Y F, Zhou H F, Xu L G. Dynamic variations of soil moisture in Haloxylon ammodendron root zone in Gurbantunggut Desert[J]. Chinese Journal of Applied Ecology, 2011, 22(7): 1711-1716. pmid: 22007445
[26]	戴智慧, 蒋太明, 刘洪斌. 土壤水分入渗研究进展[J]. 贵州农业科学, 2008(5): 77-80.
	[Dai Zhihui, Jiang Taiming, Liu Hongbin. Research progress in soil water infiltration[J]. Guizhou Agricultural Sciences, 2008(5): 77-80.]
[27]	Fu C F, Bian Z H, Xi J J, et al. Spatial distribution characteristics of soil moisture in different types of sand dune in the Mu Us Sandy Land, adjacent to north of Chinese Loess Plateau[J]. Environmental Earth Sciences, 2018, 77(4): 1-12. doi: 10.1007/s12665-017-7169-5
[28]	Yue K, de Frenne P, Fornara D A, et al. Global patterns and drivers of rainfall partitioning by trees and shrubs[J]. Global Change Biology, 2021, 27(14): 3350-3357. doi: 10.1111/gcb.v27.14
[29]	Liu X, Lu K X, Li P, et al. Research and simulation of soil water infiltration on slope under different rainfall conditions[J]. Journal of Arid Land Resources and Environment, 2018, 32: 114-118.
[30]	Cheng L P, Liu W Z, Li Z. Soil water in deep layers under different land use patterns on the Loess Tableland[J]. Acta Ecologica Sinica, 2014, 8: 1975-1983.
[31]	Song G, Li X R, Hui R. Biological soil crusts increase stability and invasion resistance of desert revegetation communities in northern China[J]. Ecosphere, 2020, 11(2): e03043, doi: 10.01002/ecs03042.03043.
[32]	张雪, 张春平, 杨晓霞, 等. 草地和荒漠生态系统生物土壤结皮对土壤养分及酶活性的影响[J]. 草地学报, 2023, 31(3): 632-640. doi: 10.11733/j.issn.1007-0435.2023.03.002
	[Zhang Xue, Zhang Chunping, Yang Xiaoxia, et al. Effects of biological soil crusts on soil nutrient and enzyme activities in grassland and desert ecosystems[J]. Acta Agrestia Sinica, 2023, 31(3): 632-640.] doi: 10.11733/j.issn.1007-0435.2023.03.002
[33]	龚萍, 党晓宏, 蒙仲举, 等. 生物结皮对沙质土壤水含量和水分入渗的影响[J]. 干旱区资源与环境, 2022, 36(9): 120-125.
	[Gong Ping, Dang Xiaohong, Meng Zhongju, et al. Effect of biological crusts on soil water infiltration in coal mining subsided sandy land[J]. Journal of Arid Land Resources and Environment, 2022, 36(9): 120-125.]
[34]	Fernandez-Illescas C P, Porporato A, Laio F, et al. The ecohydrological role of soil texture in a water-limited ecosystem[J]. Water Resources Research, 2001, 37(12): 2863-2872. doi: 10.1029/2000WR000121
[35]	李笑吟, 毕华兴, 张志, 等. 晋西黄土区坡面尺度地形因子对土壤水分状况的影响[J]. 北京林业大学学报, 2006(4): 51-56.
	[Li Xiaoyin, Bi Huaxing, Zhang Zhi, et al. Impact of terrain factors on soil moisture in slopes of western Shanxi Province in loess area[J]. Journal of Beijing Forestry University, 2006(4): 51-56.]
[36]	赵建文, 李金麟, 王圣杰. 祁连山土壤水分时空变化特征及主要驱动因素分析[J]. 干旱区地理, 2025, 48(8): 1480-1491.
	[Zhao Jianwen, Li Jinlin, Wang Shengjie. Characteristics of spatial and temporal variation of soil moisture and analysis of main driving factors in the Qilian Mountains[J]. Arid Land Geography, 2025, 48(8): 1480-1491.] doi: 10.12118/j.issn.1000-6060.2024.664
[37]	Tian S G. Effect analysis on rainwater conservation benefit of concave herbaceous field in Jinan City[J]. Advanced Materials Research, 2013, 2480(726-731): 3685-3689.
[38]	Sharma S, Carlson J D, Krueger E S, et al. Soil moisture as an indicator of growing-season herbaceous fuel moisture and curing rate in grasslands[J]. International Journal of Wildland Fire, 2020, 30(1): 57-69. doi: 10.1071/WF19193
[39]	杨维西. 试论我国北方地区人工植被的土壤干化问题[J]. 林业科学, 1996(1): 78-85.
	[Yang Weixi. The preliminary discussion on soil desiccation of artificial vegetation in the northern regions of China[J]. Scientia Silvae Sinicae, 1996(1): 78-85.]
[40]	石莎, 冯金朝, 邹学勇. 不同地形条件对沙漠植物生长和沙地土壤水分的影响[J]. 干旱区地理, 2007, 30(6): 846-851. doi: 10.13826/j.cnki.cn65-1103/x.2007.06.014
	[Shi Sha, Feng Jinzhao, Zou Xueyong. Effects of the fixed dune topography on soil water and plant growth[J]. Arid Land Geography, 2007, 30(6): 846-851.]
[41]	李玉山. 黄土区土壤水分循环特征及其对陆地水分循环的影响[J]. 生态学报, 1983, 3(2): 91-101.
	[Li Yushan. The properties of water cycle in soil and their effect on water cycle for land in the loess region[J]. Acta Ecologica Sinica, 1983, 3(2): 91-101.]
[42]	Zipper S C, Soylu M E, Booth E G, et al. Untangling the effects of shallow groundwater and soil texture as drivers of subfield-scale yield variability[J]. Water Resources Research, 2015, 51(8): 6338-6358. doi: 10.1002/wrcr.v51.8
[43]	Li X R, Zhang Z S, Huang L, et al. Review of the ecohydrological processes and feedback mechanisms controlling sand-binding vegetation systems in sandy desert regions of China[J]. Chinese Science Bulletin, 2013, 58(13): 1483-1496. doi: 10.1007/s11434-012-5662-5
[44]	程洪, 张新全. 草本植物根系网固土原理的力学试验探究[J]. 水土保持通报, 2002, 22(5): 20-23.
	[Cheng Hong, Zhang Xinquan. An experimental study on herb plant root system for strength principle of soil-fixation[J]. Bulletin of Soil and Water Conservation, 2002, 22(5): 20-23.]
[45]	Cao W, Sheng Y, Wu J C, et al. Spatial variability and its main controlling factors of the permafrost soil-moisture on the northern-slope of Bayan Har Mountains in Qinghai-Xizang Plateau[J]. Journal of Mountain Science, 2017, 14(12): 2406-2419. doi: 10.1007/s11629-017-4467-z
[46]	Zhang H X, Chang J X, Zhang L P, et al. NDVI dynamic changes and their relationship with meteorological factors and soil moisture[J]. Environmental Earth Sciences, 2018, 77(16): 1-11. doi: 10.1007/s12665-017-7169-5
[47]	Najafifar A, Hosseinzadeh J, Karamshahi A. The role of hillshade, aspect, and toposhape in the woodland dieback of arid and semi-arid ecosystems: A case study in Zagros woodlands of Ilam Province, Iran[J]. Journal of Landscape Ecology, 2019, 12(2): 79-91. doi: 10.2478/jlecol-2019-0011
[48]	Jakšić S, Ninkov J, Milić S, et al. Influence of slope gradient and aspect on soil organic carbon content in the region of Niš, Serbia[J]. Sustainability, 2021, 13(15): 8332, doi: 10.3390/su13158332.
[49]	张起鹏, 路红娥, 赵頔琛, 等. 甘南黄河上游植被覆盖度时空变化与地形因子的关系[J]. 干旱区研究, 2025, 42(3): 523-533. doi: 10.13866/j.azr.2025.03.12
	[Zhang Qipeng, Lu Honge, Zhao Dichen, et al. Relationship between temporal and spatial changes of vegetation coverage and topographic factors in the upper Yellow River in Gannan[J]. Arid Zone Research, 2025, 42(3): 523-533.] doi: 10.13866/j.azr.2025.03.12
[50]	Chen N, Zhang Y F, Zhao C M. On the importance of stemflow to the woody plants in drylands: Individual vs. ecosystem scales[J]. Journal of Hydrology, 2021, 601(1): 126591, doi: 10.1016/j.jhydrol.2021.126591.
[51]	Ankenbauer K J, Loheide I S P. The effects of soil organic matter on soil water retention and plant water use in a meadow of the Sierra Nevada, CA[J]. Hydrological Processes, 2017, 31(4): 891-901. doi: 10.1002/hyp.11070
[52]	赵美亮, 曹广超, 赵青林, 等. 祁连山阿咪东索小流域典型水文年草地和灌丛坡面产流特征研究[J]. 干旱区研究, 2026, 43(4): 729-741. doi: 10.13866/j.azr.2026.04.05
	[Zhao Meiliang, Cao Guangchao, Zhao Qinglin, et al. Study on the runoff characteristics of grassland and shrub slope in typical hydrological years in the Amidongsuo sub-watershed of the Qilian Mountains[J]. Arid Zone Research, 2026, 43(4): 729-741.] doi: 10.13866/j.azr.2026.04.05

地名	经度/E	纬度/N	海拔/m	地貌类型	样地大小	优势固沙灌木
北沙窝	87°55′12″	44°22′24″	410	固定沙丘	40 m×148 m	梭梭、驼绒藜、蛇麻黄
彩南油田石油管理处	88°16′35″	44°33′34″	478	半固定沙丘	40 m×180 m	白梭梭、驼绒藜、沙拐枣、沙蒿
彩南油田	88°32′28″	44°56′49″	622	流动沙丘	40 m×148 m	白梭梭、沙拐枣、准噶尔无叶豆

参数	固定沙丘	半固定沙丘	流动沙丘
max_depth	10	5	5
max_features	0.8	0.8	0.8
min_samples_leaf	4	1	2
min_samples_split	2	5	2
n_estimators	100	100	100

评价指标	固定沙丘中层	半固定沙丘表层	流动沙丘深层
决定系数（R²）	0.62	0.68	0.60
均方根误差	0.40	0.16	0.40
平均绝对误差	0.33	0.13	0.31
