W-OH阻水层对煤矸石坡面降雨入渗以及产流产沙过程影响

doi:10.12118/j.issn.1000-6060.2024.731

Abstract

Abstract:

Aiming at the problem of water leakage and frozen soil formation of coal gangue slope in Muli mining area of Qinghai Province, water-blocking layers with different concentrations of hydrophilic polyurethane (W-OH, 0%, 1.5%, 2.5%, 3.5%, 4.5%) were constructed on the coal gangue slope, and the characteristic parameters of rainfall infiltration, runoff and sediment on the slope were analyzed by artificial rainfall simulation. The effects of water-blocking layers with different concentrations of W-OH on the rainfall infiltration and runoff-producing and sediment-producing process of the coal gangue slope were revealed. The results showed that: (1) Under slope of 5°, 15°, 25° and rainfall intensity of 30~90 mm·h^-1, the overall change trend of slope infiltration rate with different W-OH concentrations showed a rapid decline at first and then tended to be stable, and the higher the W-OH concentration, the earlier the stable infiltration stage was reached. (2) The average infiltration rate of slope under different W-OH concentration was decreased by 4.15%-73.64% compared with the control group (0%W-OH). The water-blocking effects of 1.5%, 2.5%, 3.5% and 4.5% W-OH on slope surface were 5.49%-49.98%, 11.96%-65.91%, 16.61%-72.10% and 22.92%-85.81%, respectively, and increased with the increase of W-OH concentration. (3) The initial runoff generation time on the slope with different W-OH concentrations was 1.95%-74.20% earlier than that on the control slope. The sediment yield effects of 1.5%, 2.5%, 3.5% and 4.5% W-OH on the slope were 7.68%-97.98%, 15.28%-163.00%, 25.44%-261.44% and 25.61%-260.58%, respectively, which were negatively correlated with rainfall intensity and slope, and positively correlated with W-OH concentration. Runoff yield effect were 5.20%-83.39%, 12.93%-131.18%, 14.14%-149.11% and 16.28%-188.86%. (4) The correlation analysis of relevant indicators shows that the W-OH water-blocking layer plays an important role in preventing water infiltration and increasing sediment yield, and rain intensity and slope are still the dominant factors in the process of sediment yield on slope. It is found that the construction of W-OH water-blocking layer on the coal gangue slope can play a good role in reducing seepage and water blocking, and also increase the runoff-producing and sediment-producing on the slope. Considering the problem of soil and water loss, some soil and water conservation measures can be configured on the slope.

Key words: coal gangue, rainfall infiltration, runoff and sediment yield, water-blocking layers

LU Changjin, WANG Zhigang, YANG Hailong, WU Miaochen, YIN Wentian. Impact of W-OH water-blocking layers on rainfall infiltration, runoff and sediment yield processes on coal gangue slopes[J].Arid Land Geography, 2025, 48(9): 1623-1635.

Figures/Tables 13

Tab. 1

Fig. 1

Tab. 2

Fig. 2

Fig. 3

Tab. 3

Fig. 4

Fig. 5

Tab. 4

Fig. 6

Fig. 7

Tab. 5

Tab. 6

References 25

[1]	魏忠义, 王秋兵. 大型煤矸石山植被重建的土壤限制性因子分析[J]. 水土保持研究, 2009, 16(1): 179-182.
	[Wei Zhongyi, Wang Qiubing. Research on limited factors of reclaimed soil in the large coal wastes pile in Fushun west opencast coal mine[J]. Research of Soil and Water Conservation, 2009, 16(1): 179-182.]
[2]	魏忠义, 陆亮, 王秋兵. 抚顺西露天矿大型煤矸石山及周边土壤重金属污染研究[J]. 土壤通报, 2008, 39(4): 946-949.
	[Wei Zhongyi, Lu Liang, Wang Qiubing. Research on the heavy metal contamination of Funshun west coal wastes pile and its adjacent soil[J]. Chinese Journal of Soil Science, 2008, 39(4): 946-949.]
[3]	刘志斌, 张跃进, 王娟. 煤矸石淋溶水环境影响的分析研究[J]. 辽宁工程技术大学学报(自然科学版), 2005(2): 280-283.
	[Liu Zhibin, Zhang Yuejin, Wang Juan. Research of influence of leaching water of gangue on environments[J]. Journal of Liaoning Technical University (Natural Science Edition), 2005(2): 280-283.]
[4]	王毓军, 谢维, 孙翠玲, 等. 抚顺西露天矿排土场环境质量状况研究[J]. 辽宁城乡环境科技, 2005, 25(5): 36-38.
	[Wang Yujun, Xie Wei, Sun Cuiling, et al. Study on environmental quality at the dump of Fushun western open-pit core mine[J]. Liaoning Urban and Rural Environmental Science & Technology, 2005, 25(5): 36-38.]
[5]	胡晓萧, 李小英. 矿山废弃地生态修复中土壤基质改良技术研究综述[J]. 现代农业科技, 2018(1): 184-186, 190.
	[Hu Xiaoxiao, Li Xiaoying. Review on improvement of soil matrix in ecological restoration of abandoned mines[J]. Modern Agricultural Science and Technology, 2018(1): 184-186, 190.]
[6]	刘得俊, 孙广春, 李润杰, 等. W-OH渠道防渗抗冻新材料的开发和施工工艺[C]// 第二届全国灌区及水工建筑物防渗抗冻胀技术与生态建设交流研讨会论文集. 乌鲁木齐: 中国水利技术信息中心, 2010: 4-9.
	[Liu Dejun, Sun Guangchun, Li Runjie, et al. Development and construction technology of W-OH channel anti-seepage and frost-resistant new materials[C]// Proceedings of the Second National Conference on Anti-seepage and Frost-resistant Technology and Ecological Construction of Irrigation Areas and Hydraulic Structures. Urumqi: China Water Conservancy Technology Information Center, 2010: 4-9.]
[7]	高卫民, 吴智仁, 吴智深, 等. 荒漠化防治新材料W-OH的力学性能研究[J]. 水土保持学报, 2010, 24(5): 1-5.
	[Gao Weimin, Wu Zhiren, Wu Zhishen, et al. Study on mechanical properties of a novel desertification prevention material of W-OH[J]. Journal of Soil and Water Conservation, 2010, 24(5): 1-5.]
[8]	祝亚云, 曹龙熹, 吴智仁, 等. 新型W-OH材料对崩积体土壤分离速率的影响[J]. 土壤学报, 2017, 54(1): 73-80.
	[Zhu Yayun, Cao Longxi, Wu Zhiren, et al. Impact of W-OH on soil detachment rate of colluvial deposits in collapsing hill[J]. Acta Pedologica Sinica, 2017, 54(1): 73-80.]
[9]	余莹莹, 汪永进, 范敬兰, 等. W-OH生态护坡技术在沙土区河道坡面上的应用[J]. 治淮, 2014(8): 31-32.
	[Yu Yingying, Wang Yongjin, Fan Jinglan, et al. Application of W-OH eco-slope protection technology on sandy soil river slopes[J]. Harnessing the Huaihe River, 2014(8): 31-32.]
[10]	郭凯先. W-OH新材料特性及在青海湖周边地区沙化地植生固沙中的应用[J]. 中国农村水利水电, 2012(4): 30-32, 37.
	[Guo Kaixian. Characteristics of the new chemical material W-OH in the revegetation of desertified areas around Qinghai Lake and their application[J]. China Rural Water and Hydropower, 2012(4): 30-32, 37.]
[11]	王欣, 朱绪超, 梁音, 等. 新型W-OH材料对南方典型侵蚀土壤入渗和产流产沙的影响[J]. 中国水土保持科学(中英文), 2020, 18(6): 123-131.
	[Wang Xin, Zhu Xuchao, Liang Yin, et al. Effects of new polyurethane material (W-OH) on infiltration and runoff andsediment yield of two typical erodible soils in south China[J]. Science of Soil and Water Conservation, 2020, 18(6): 123-131.]
[12]	张颂扬, 张巍, 杨鹏辉, 等. 模拟降雨条件下重构阻水层对坡面风化煤矸石产流产沙的影响[J]. 水土保持通报, 2024, 44(2): 101-109.
	[Zhang Songyang, Zhang Wei, Yang Penghui, et al. Effect of reconstructed water-blocking layers on sediment production from weathered coal gangue on slopes under simulated rainfall conditions[J]. Bulletin of Soil and Water Conservation, 2024, 44(2): 101-109.]
[13]	李毅, 邵明安. 人工草地覆盖条件下降雨入渗影响因素的实验研究[J]. 农业工程学报, 2007(3): 18-23.
	[Li Yi, Shao Ming’an. Experimental study on influence factors of rainfall and infiltration under artificial grassland coverage[J]. Transactions of the Chinese Society of Agricultural Engineering, 2007(3): 18-23.]
[14]	李元元, 王占礼, 刘俊娥, 等. 喷施中性多聚糖对黄土坡面降雨入渗的影响[J]. 土壤学报, 2017, 54(4): 844-853.
	[Li Yuanyuan, Wang Zhanli, Liu Jun’e, et al. Effect of spraying Jag S on rain water infiltration on loess slope[J]. Acta Pedologica Sinica, 2017, 54(4): 844-853.]
[15]	焦若禺, 宋孝玉, 赵新凯, 等. 黄土沟壑区黑麦草植被冠层与根系坡面水沙效益及水力特性[J]. 干旱区地理, 2022, 45(1): 208-218. doi: 10.12118/j.issn.1000–6060.2021.154
	[Jiao Ruoyu, Song Xiaoyu, Zhao Xinkai, et al. Runoff and sediment yield benefits and hydraulic characteristics of perennial ryegrass plantation canopy and root slope in the Loess Plateau[J]. Arid Land Geography, 2022, 45(1): 208-218.] doi: 10.12118/j.issn.1000–6060.2021.154
[16]	高露双, 许丽, 尹忠东, 等. 阜新矸石山土壤渗透性的研究[J]. 水土保持研究, 2006(3): 45-46.
	[Gao Lushuang, Xu Li, Yin Zhongdong, et al. Study on soil permeability of waste rock hill[J]. Research of Soil and Water Conservation, 2006(3): 45-46.]
[17]	刘瑾, 亓孝辉, 张达, 等. 聚氨酯型固化剂改良表层砂土抗渗透特性试验[J]. 地球科学与环境学报, 2017, 39(1): 126-134.
	[Liu Jin, Qi Xiaohui, Zhang Da, et al. Experiment on penetration resistance of surface sandy soil stabilized by polyurethane soil stabilizers[J]. Journal of Earth Sciences and Environment, 2017, 39(1): 126-134.]
[18]	张俊魁, 高海鹰, 梁止水. 水溶性聚氨酯改良砒砂岩的水理性能试验研究[J]. 水土保持通报, 2018, 38(1): 103-106.
	[Zhang Junkui, Gao Haiying, Liang Zhishui. Water-physical properties of feldspathic sandstone modified by hydraulic polyurethane[J]. Bulletin of Soil and Water Conservation, 2018, 38(1): 103-106.]
[19]	杨鹏辉, 杨海龙, 杨思远, 等. W-OH固化剂对高寒矿区煤矸石水分入渗的影响及模型拟合[J]. 干旱区地理, 2024, 47(9): 1542-1554. doi: 10.12118/j.issn.1000-6060.2023.661
	[Yang Penghui, Yang Hailong, Yang Siyuan, et al. Effect of W-OH stabilizer on water infiltration of coal gangue in high-cold mining areas and model fitting[J]. Arid Land Geography, 2024, 47(9): 1542-1554.] doi: 10.12118/j.issn.1000-6060.2023.661
[20]	蒋定生, 黄国俊. 地面坡度对降雨入渗影响的模拟试验[J]. 水土保持通报, 1984, 4(4): 10-13.
	[Jiang Dingsheng, Huang Guojun. Simulation experiment on the impact of ground slope on rainfall infiltration[J]. Bulletin of Soil and Water Conservation, 1984, 4(4): 10-13.]
[21]	朱秀迪, 丁文峰, 张冠华, 等. 新型水溶性聚氨酯对紫色土坡面产流产沙的影响[J]. 长江科学院院报, 2018, 35(1): 47-51. doi: 10.11988/ckyyb.20161043
	[Zhu Xiudi, Ding Wenfeng, Zhang Guanhua, et al. Impact of new water-soluble polyurethane on runoff and sediment yield on purple soil slope[J]. Journal of Changjiang River Scientific Research Institute, 2018, 35(1): 47-51.]
[22]	耿晓东, 郑粉莉, 张会茹. 红壤坡面降雨入渗及产流产沙特征试验研究[J]. 水土保持学报, 2009, 23(4): 39-43.
	[Geng Xiaodong, Zheng Fenli, Zhang Huiru. Effect of rainfall intensities and slope gradients on characteristics of rainfall infiltration, runoff and sediment on red soil[J]. Journal of Soil and Water Conservation, 2009, 23(4): 39-43.]
[23]	李睿杰, 杨建英, 赵廷宁, 等. 生态棒间隔距离对铁尾矿坡面减流减沙效应的影响[J]. 农业工程学报, 2024, 40(9): 98-107.
	[Li Ruijie, Yang Jianying, Zhao Tingning, et al. Influences of ecobar spacing distance on flow and sand reduction of iron tailings slopes[J]. Transactions of the Chinese Society of Agricultural Engineering, 2024, 40(9): 98-107.]
[24]	李裕元, 邵明安. 土壤翻耕对坡地水分转化与产流产沙特征的影响[J]. 农业工程学报, 2003(1): 46-50.
	[Li Yuyuan, Shao Ming’an. Impact of tillage on water transformation and runoff-sediment-yielding characteristics on slope land[J]. Transactions of the Chinese Society of Agricultural Engineering, 2003(1): 46-50.]
[25]	李猛, 陈瑞华, 席光超, 等. 矿区废弃地水土保持措施配置探讨[J]. 绿色科技, 2012(11): 180-184.
	[Li Meng, Chen Ruihua, Xi Guangchao, et al. Study of soil and water conservation measures in mining wasteland[J]. Journal of Green Science and Technology, 2012(11): 180-184.]

容重/g·cm^-3	含水量/%	粒径组成/%
容重/g·cm^-3	含水量/%	<0.1 mm	0.1~0.5 mm	0.5~1.0 mm	1.0~2.0 mm	2.0~10.0 mm	>10.0 mm
1.62	13.70	5.73	12.33	12.56	6.61	38.55	24.23

W-OH 浓度/%	雨强30 mm·h^-1			雨强60 mm·h^-1			雨强90 mm·h^-1
W-OH 浓度/%	坡度5°	坡度15°	坡度25°	坡度5°	坡度15°	坡度25°	坡度5°	坡度15°	坡度25°
0.0	1333	1262	1015	973	551	313	302	188	156
1.5	1307	1058	972	528	394	207	224	140	128
2.5	1286	902	876	294	291	182	194	119	107
3.5	1069	844	839	251	238	212	149	91	83
4.5	1061	782	756	194	172	153	111	90	66

坡度/(°)	雨强/mm·h^-1	累计入渗量/L					阻水效应/%
坡度/(°)	雨强/mm·h^-1	1.5%W-OH	2.5%W-OH	3.5%W-OH	4.5%W-OH	0%W-OH	1.5%W-OH	2.5%W-OH	3.5%W-OH	4.5%W-OH
5	30	18.81	16.81	15.23	14.18	19.90	5.49	15.55	23.46	28.75
	60	25.31	18.54	16.27	11.23	35.16	28.00	47.27	53.73	68.05
	90	17.98	12.54	9.85	6.55	20.64	12.88	39.26	52.29	68.28
15	30	15.30	14.08	13.80	12.76	16.55	7.57	14.95	16.61	22.92
	60	21.14	16.04	13.32	6.92	32.61	35.17	50.83	59.15	78.77
	90	10.95	8.45	5.91	4.03	17.27	36.61	51.09	65.79	76.66
25	30	13.81	13.28	11.95	10.79	15.08	8.44	11.96	20.74	28.44
	60	18.58	11.17	9.46	4.07	28.69	35.23	61.07	67.03	85.81
	90	5.35	3.65	2.99	1.82	10.70	49.98	65.91	72.10	82.98

坡度/(°)	雨强/mm·h^-1	累计产沙量/g					产沙效应/%
坡度/(°)	雨强/mm·h^-1	1.5%W-OH	2.5%W-OH	3.5%W-OH	4.5%W-OH	0%W-OH	1.5%W-OH	2.5%W-OH	3.5%W-OH	4.5%W-OH
5	30	9.29	12.20	12.00	16.16	4.77	94.69	155.59	151.40	238.55
	60	31.84	54.73	67.27	66.38	22.00	44.73	148.79	205.76	201.73
	90	45.48	75.81	87.35	93.67	28.83	57.77	163.00	203.01	224.93
15	30	10.59	14.01	17.75	22.97	7.03	50.66	99.32	152.56	226.94
	60	75.59	73.92	82.55	88.27	52.01	45.32	42.12	58.70	69.70
	90	83.19	84.87	92.21	110.57	71.28	16.70	19.06	29.37	55.13
25	30	18.35	22.37	33.49	33.41	9.27	97.98	141.44	261.44	260.58
	60	76.77	85.52	106.80	116.00	66.17	16.02	29.24	61.39	75.30
	90	137.35	147.04	160.00	160.21	127.55	7.68	15.28	25.44	25.61

坡度/(°)	雨强/mm·h^-1	累计产流量/L					产流效应/%
坡度/(°)	雨强/mm·h^-1	1.5%W-OH	2.5%W-OH	3.5%W-OH	4.5%W-OH	0%W-OH	1.5%W-OH	2.5%W-OH	3.5%W-OH	4.5%W-OH
5	30	5.10	7.10	8.68	9.73	4.01	27.26	77.21	116.46	142.74
	60	22.51	29.28	31.56	36.59	12.67	77.69	131.18	149.11	188.86
	90	53.75	59.19	61.89	65.19	51.09	5.20	15.86	21.13	27.59
15	30	7.88	9.10	9.38	10.42	6.63	18.91	37.33	41.47	57.22
	60	25.22	30.33	33.04	39.44	13.75	83.39	120.52	140.26	186.78
	90	58.60	61.10	63.64	65.51	52.27	12.10	16.88	21.74	25.33
25	30	7.94	8.48	9.80	7.94	6.67	19.08	27.04	46.89	64.29
	60	27.78	35.20	36.91	27.78	17.68	57.16	99.09	108.76	139.23
	90	59.90	61.61	62.27	59.90	54.55	9.81	12.93	14.14	16.28

Impact of W-OH water-blocking layers on rainfall infiltration, runoff and sediment yield processes on coal gangue slopes

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 13

References 25

Related Articles 1

Metrics

Comments

Recommended 0

变量	初始产流时间	平均入渗率	阻水效应	平均产沙率	产沙效应	平均产流率	产流效应
雨强	-0.869^**	-0.122	0.551^**	0.810^**	-0.465^**	0.076	-0.299
坡度	-0.211	-0.419^**	0.376^*	0.355^*	-0.373^*	0.955^**	-0.229
浓度	-0.254	-0.661^**	0.613^**	0.302^*	0.495^**	0.222	0.398^*
